Kích lắc tay thủy lực có khóa Hi-Force JAH1260SR

Kích lắc tay thủy lực có khóa Hi-Force JAH1260SR
• Xuất xứ: UK

• Giao hàng: 3-5 ngày nếu hàng có sẵn kho.

• Bảo hành: 12 tháng.

• Chứng chỉ: COO, CO, CQ.

• Hướng dẫn và chuyển giao công nghệ tại Kho khách hàng.

The JAH range of lightweight aluminium jacks offers a wide variety of capacities and lift height options. Available as either plain ram lifting jacks, with or without “failsafe” mechanical lock ring, or optional low height claw lifting design, all models are constructed predominantly of lightweight aluminium alloy with all critical functioning parts manufactured from high quality steel. Used extensively in maintenance, construction, heavy plant and machinery applications, these high quality jacks are the proven industry standard.

• Capacities from 20 to 60 tonnes
• Stroke lengths up to 305 mm
• Internal safety overload device
• Lightweight construction
• Available with plain piston, lifting claw or failsafe mechanical lock ring
• Claw lift capacities from 8 to 24 tonnes
• Stroke limiting device

Model Number	Jack capacity tonners	Claw capacity tonners	Stroke mm	Weight kg
Jack with plain piston
JAH620	20	–	152	11.0
JAH1220	20	–	305	17.0
JAH630	30	–	152	16.0
JAH1230	30	–	305	24.0
JAH660	60	–	152	28.0
JAH1260	60	–	305	44.0
Jack with plan piston and lifting claw with extended base
JAH620C	20	8	152	15.0
JAH1220C	20	8	305	23.0
JAH630C	30	12	152	21.0
JAH1230C	30	12	305	32.0
JAH660C	60	24	152	44.0
JAH1260C	60	24	305	65.0
Jack with failsafe mechanical load holding lock ring
JAH620SR	20	–	152	13.0
JAH220SR	20	–	305	19.0
JAH630SR	30	–	152	17.0
JAH1230	30	–	305	25.0
JAH660SR	60	–	152	30.0
JAH1260SR	60	–	305	46.0



Dimensions in mm
Model Number	A	A1	A2	B	B1	C	D	E	F
Jack with plain piston
JAH620	263	–	–	178	–	121	57	–	60
JAH1220	438	–	–	–	246	121	57	–	60
JAH630	263	–	–	203	–	140	70	–	76
JAH1230	451	–	–	–	273	140	70	–	76
JAH660	293	–	–	251	–	190	92	–	108
JAH1260	500	–	–	–	342	190	92	–	108
Jack with plan piston and lifting claw with extended base
JAH620C	–	280	–	–	246	121	57	67	–
JAH1220C	–	456	–	–	246	121	57	67	–
JAH630C	–	281	–	–	273	140	70	78	–
JAH1230C	–	472	–	–	273	140	70	78	–
JAH660C	–	335	–	–	342	190	92	78	–
JAH1260C	–	545	–	–	342	190	92	78	–
Jack with failsafe mechanical load holding lock ring
JAH620SR	–	–	289	178	–	121	57	–	60
JAH220SR	–	–	464	–	246	121	57	–	60
JAH630SR	–	–	292	203	–	140	70	–	76
JAH1230	–	–	479	–	273	140	70	–	76
JAH660SR	–	–	330	251	–	190	92	–	108
JAH1260SR	–	–	536	–	342	190	92	–	108
